Project Description

CBB65 Oval metalized polypropylene AC capacitor



Features:

1. Oval- shape metal case, two groups of lug terminals.

2. With inner anti-explosion device, safe and reliable.

3. Low dissipation factor, high insulation resistance ,good slef-healing, stable performance, good ability of resisting impact current and overload.

4.Suitble for air conditioner, refrgierator, washing machine, light etc and beneficial to the starting and running of AC motor.

Technical Data:

CBB65 Oval Capacitor
Capacity	Size	Capacity (Dual)	Size
4UF	31.5*51.5*55	15+1.5UF	45*71*65
5UF	31.5*51.5*55	20+1.5UF	45*71*65
7.5UF	31.5*51.5*55	15+5UF	45*71*65
10UF	31.5*51.5*65	20+5UF	45*71*65
12.5UF	31.5*51.5*75	25+1.5UF	45*71*65
15UF	31.5*51.5*75	25+3UF	45*71*75
17UF	31.5*51.5*75	25+5UF	45*71*75
17/17.5UF	31.5*51.5*85	25+7.5UF	45*71*75
20UF	31.5*51.5*85	30+2UF	45*71*85
20UF	45*71*65	30+5UF	45*71*85
25UF	45*71*75	30+7.5UF	45*71*85
30UF	45*71*75	35+2UF	45*71*85
35UF	45*71*75	35+5UF	45*71*90
40UF	45*71*85	35+7.5UF	45*71*90
45UF	45*71*90	40+5UF	45*71*100
50UF	45*71*100	40+7.5UF	45*71*100
55UF	45*71*100	45+5UF	45*71*110
60UF	45*71*110	45+6UF	45*71*110
65UF	45*71*110	45+7.5UF	45*71*110
70UF	45*71*125	50+5UF	45*71*120
75UF	48*90*90	50+6UF	45*71*120
80UF	48*90*100	50+7.5UF	45*71*120
100UF	48*90*110	55+5UF	45*71*125
		55+6UF	45*71*125
		55+7.5UF	45*71*125
		60+5UF	48*90*100
		60+6UF	48*90*100
		60+7.5UF	48*90*100
		65+5UF	48*90*100
		70+5UF	48*90*100
		70+7.5UF	48*90*100
		80+5UF	48*90*110
		80+7.5UF	48*90*110

Outline Dimensions:

Capacitance Range	250 - 300VAC			370-400VAC			440-450VAC
	L(mm)	B(mm)	H(mm)	L(mm)	B(mm)	H(mm)	L(mm)	B(mm)	H(mm)
5 - 100uf	31.5 - 45	51.5 - 70.5	50-125	31.5-47.6	51.5-90	50-125	31.5-47.6	51.5-90	50-125
